straight bnc female connector for PCB mount

Price:	1.0~2.0 USD
Payment Terms:	T/T,L/C,D/A,D/P,WU;paypal
Place of Origin:	Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Model No.: 612

Production Capacity: 100000pcs

Delivery Date: 7days

Frequency Range: DC 0-4GHZ

impedance: 50 ohm or 75 ohm

Business type: : bnc connector/manufacture...

Insulators: ABS/PP/PVC/PBT/pPTFE

Warranty: 12months

Means of Transport: Ocean,Land,Air;EXPRESS

Packing: box

material: zinc and brass

connector part: bnc male cable, bnc pcb

color: nickel plated

rf connector: bnc connectors

Center Pin: Pure Copper

rf coaxial bnc single connector
1.Material:copper/zinc
2.Insulator:PTFE/POM
3.Certification:RoHS/ISO9001:2001

Features:
1.Bayonet coupling mechanism provides quick mating and unmating
2.50ohm and 75ohm are intermateable to ensure non-destructive mating
3.Various options of connectors are available for different use

Applications:
·Antennas
·Automotive
·Cable Modems
·Computers/LANs
·Medical Equipment
·Radios
·Telecom

Specifications:

Impedance	50 ohm	75 ohm
Frequency range	0-4 GHz	0-1 GHz
Temperature	-65 °C — +165°C
Working voltage	500 VRMS max
Dielectric withstanding voltage	1500 VRMS min
VSWR	Straight 1.3 max
	Right angle 1.5 max
Contact resistance	Center contact 3 milliohms max
	Outer contact 2 milliohms max
Insulator resistance	5000 megohms min
